Mini Thermal Printer GOOJPRT QR204 58mm Super Mini Embedded Receipt Printer RS232 / TTL + USB Panel Printers
 |
Product Details:
| Place of Origin: | Xiamen |
| Brand Name: | GOOJPRT |
| Certification: | CE/ROSH/FCC |
| Model Number: | JR-QR204 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 18 |
| Packaging Details: | Carton |
| Delivery Time: | 5day shipping |
| Payment Terms: | T/T |
| Supply Ability: | 50000pcs/month |
| Minimum Order Quantity: | The more, the better |
Detailed Product Description
Mini Thermal Printer GOOJPRT QR204 58mm Super Mini Embedded Receipt Printer RS232 / TTL + USB Panel Printers
A. beautiful shape
B. Easy paper loading
C. Low noise, thermal printing
D. Optional different interface
Replace the paper structure E. Front Panel
F. easily embedded in a variety of different instruments and meters
G. supports ESC / POS print instruction set
Model : JP-QR204
Product Features :
A. beautiful shape
B. Easy paper loading
C. Low noise, thermal printing
D. Optional different interface
Replace the paper structure E. Front Panel
F. easily embedded in a variety of different instruments and meters
G. supports ESC / POS print instruction set
Applications:
A. taximeter
B. Recorder
C. Self-service equipment
D. vending machines
E. Medical Instruments
F. Weighing
G. electronic equipment
H. Test Equipment
Specifications:
Print
Printing method
Thermal
Print speed
50 - 85 mm / sec
Resolution
8 dots / mm , 384 dots / line
Effective print width
48 mm
Character
Character Set
ASCII, GB2312-80 ( Chinese )
Print
ANK: 5 × 7, Chinese : 12x24, 24 × 24
Paper Specifications
Paper Type
Thermal paper
Paper width
57.5 ± 0.5MM
Paper Thickness
0.06 to 0.07 millimeters
Roll Diameter
Maximum: 30 mm
Reliability
MTBF cycle (MCBF)
5 million lines
Communication Interface
Serial (RS-232C, TTL), Parallel
Embed depth
43 mm
Power ( adapter )
5V-9V DC
Physical Characteristics
Dimensions ( W x H x D )
82x58x45 mm
Installation port size
77x53 mm
Color
White / Black
Environment
Operating Temperature
5 ° C ~ 50 ° C
Humidity
10% ~ 80%
Storage Temperature
-20 ° C ~ 60 ° C
Storage humidity
10% ~ 90%
